A942450b00 45A 1500Vdc 22x58mm Cartridge Fuse by Adler Electric

Description

Adler A94 series PV fuses are engineered and manufactured for use in Combiner Box and Power Storage Protection, made from the highest quality materials and tested to the highest standards

• With rated currents from 1 A to 80 A with a breaking capacity of 10 kA
• Features
  • 1500 Vdc, 22x58 mm PV fuse link with glass-fiber body
  • Rated Current: 1-80 A
  • Breaking Capacity
    • 30 kA at 1500 Vdc (1-65 A)
    • 10 kA at 1300 Vdc (70 A, 80 A)
  • Time Constant: 1-3 ms
  • Special design with silver plated caps for high-power PV applications
  • Customizable for special applications
